Z214 Premium Near Edge Wax /Resin Ribbon

In Stock
Best value in the Near-Edge Category
  • Reduce Total Cost of Ownership. 20-25% longer than standard ribbons – less change overs. Thinner ribbon properties optimize energy use - extending the life of the printhead. Proprietary back coat reduces static electricity and extends the life of the printhead
  • “Drop in” performance…Plug and Play to the OEM ribbon equivalents.
  • Excellent image density & edge definition ensures quality imprints and exceptional scan rates
  • High-level durability
  • High-speed printing up to 40 ips
  • Heat resistance up to 212°F (100°C)
  • Halogen free
Product Features

Z214 High speed, TTO near edge wax/resin thermal transfer over printer barcode ribbon is used for imprinting date, price, lot and bar codes directly onto flexible packaging. This Premium wax resin formulation is coated on a 4.0 micron PET- carrier film designed for use on TTO in-line/near edge printers at speeds up to 40 ips. This thinner film technology offers improved productivity through longer length ribbons and reduced printer downtime related to ribbon changeovers. Z214 provides excellent print darkness and is compatible with a wide range of film materials, as well as offering excellent scratch and smear resistance. Low transfer energy properties combined with our anti-static back coat allow the user to extend the life of the printhead and reduce maintenance costs.

Manufacturer Direct - As the only thermal transfer ribbon manufacturer that equipped with the vertical integration capability of PET base film, IMP offers a full line of "drop in replacement" thermal transfer barcode ribbon and hot stamp coding foil ribbon solutions at significant cost savings.

Product Applications
  • Z214 Premium Near Edge Wax /Resin Ribbon
  • Z214 Premium Near Edge Wax /Resin Ribbon
  • Z214 Premium Near Edge Wax /Resin Ribbon
  • Z214 Premium Near Edge Wax /Resin Ribbon
  • Z214 Premium Near Edge Wax /Resin Ribbon
Application
Storage
Shipping Carton
Bag of products
Distribution label
Flexible packaging
IV Bags
Printed circuit board
Printing substrate
  • Polyethylene/LDPE
  • PET
  • Metalized PET
  • Polypropylene/PP
  • Polyolefin
Industry
  • Food and Beverage
  • Healthcare and Medical Device
  • Industrial Printing
  • Retail
Product Details
SKU
Z214
Product Color
Black
Total Thickness
6.8 ± 0.3 µm
Ink Thickness
1.0 ± 0.3 µm
Electrostatic
≤ 0.15 Kv
Optical Density
≥ 2.0 D
Ink Melt Point
78° C
Storage
  • Use within 12 months recommended
  • Keep away from UV and direct sunlight
  • Temperature 5-35°C (40-95°F)
  • Humidity 20-80%
Printing Characteristics
Z214 Premium Near Edge Wax /Resin Ribbon
Certificates & Warranties
Halogen
Halogen Free
ISEGA
ISO 14001
ISO 14001
ISO 18001
ISO 18001
ISO 9001
ISO 9001
RoHS
Heavy Metals
